Shift the coordinate reference frame of the simulation

Recalculates the positions and velocities of all bodies relative to a specific target body. This effectively "anchors the camera" to the chosen body, placing it at the origin (0, 0, 0) for all time steps.

Usage

shift_reference_frame(sim_data, center_id, keep_center = TRUE)

Arguments

sim_data

A tidy `tibble` containing the output from `simulate_system()`.

center_id

The character string ID of the body to use as the new origin.

keep_center

Logical. Should the central body remain in the dataset (it will have 0 for all coordinates) or be removed? Default is `TRUE`.

Value

A tidy `tibble` with updated `x`, `y`, `z`, `vx`, `vy`, and `vz` columns.

Examples

# \donttest{
# Simulate Sun-Earth-Moon
orbit_data <- create_system() |>
  add_sun() |>
  add_body("Earth", mass = mass_earth, x = distance_earth_sun, vy = speed_earth) |>
  add_body("Moon", mass = mass_moon, x = distance_earth_sun + distance_earth_moon,
           vy = speed_earth + speed_moon) |>
  simulate_system(time_step = seconds_per_hour, duration = seconds_per_year)

# Shift view to Earth and plot
orbit_data |>
  shift_reference_frame(center_id = "Earth") |>
  plot_orbits()

# }
